10106123-5004001LF

TE	10106123-5004001LF
分类	连接器
类型	amphenol-icc
品牌	安费诺(Amphenol-ICC)
连接器类型	母端
描述	PwrBlade+® , Power Connectors, 5ACP+16S PF, Vertical, Receptacle.
Gender	Receptacle
Orientation	Vertical
Termination Style	Press-Fit
颜色	Black
Current Rating	40A max. per Low Power Contact, 58A max. per High Power Contact
Dielectric Withstanding Voltage	1000V per Low Power/Signal Contact, 2500V per High Power Contact
Voltage Rating	124V max. per Low Power/Signal Contact, 912V max. per High Power Contact
Durability (Mating cycles)	500 Mating Cycles
Material Housing	High Temperature Thermoplastic with Glass Fiber
Operating Temperature Range	-40°C to +125°C
Retention Feature	No
Packaging	Tray
Component Type	Two Piece Mid Range
Tail Length	3.43mm (0.135in)
Resistance (Contact)	Maximum for mated pair is 0.7 mΩ
Resistance (Insulation)	? 1000MΩ after Environmental Test Conditions
Plating Contact area	0.76μm (29.921μin) Gold
Guide Feature	Guide Pin
Comments	Ordering data shown is for our standard product offering. For non-standard or custom products, contact your Authorized FCI Representative.
