B322-1B7L1-11260-E100

产品描述：: BTB Connector, P=0.50mm, H=8.4mm, Vertical orientation, Plug, 60P, With MYLAR

TE	B322-1B7L1-11260-E100
分类	连接器
类型	amphenol-icc
品牌	安费诺(Amphenol-ICC)
描述	BTB Connector, P=0.50mm, H=8.4mm, Vertical orientation, Plug, 60P, With MYLAR
Gender	Header
孔位数	60
Number of Contacts	60
Number of Rows	2
Product Series	B322
Vacuum Pick-up Cap	YES
Orientation	Vertical
Termination Style	Surface Mount
Pitch	0.50mm (0.020in)
颜色	Black
Housing Height	8.4 mm
Floating Allowance	±0.60mm for X, Y Direction; 0.50mm for Z Direction
Current Rating	Signal pin AC/DC 0.5A;Power pin AC/DC 5A
Dielectric Withstanding Voltage	No short or breakdown after AC 250V, 2mA, 1min.
Voltage Rating	AC/DC 50V
Durability (Mating cycles)	100 cycles
Material Contact	Phosphor Bronze
Flammability Rating	UL 94 V-0
Tail Plating	Gold
Plating Contact Area	4&mu Min.,Gold plating at contact area; 2&mu~ 6 &mu Gold plating at solder area; 40 to 120&mu,in Nickel underplating over all
Material Housing	LCP
Operating Temperature Range	-40°C to +125°C
Retention Feature	No
Solder process	Compatible with Reflow Soldering Processes
Ul file number	E83005
Packaging	Tape/Reel
