10132583-001LF
- 类 型:
- 连接器
- 品 牌:
- 安费诺(Amphenol-ICC)
- 颜 色:
- Black
- 产品描述:
- SAS/PCIe 3.0 (U.2) Connectors, Storage and Server Connector, 68 Position Right Angle,Straddle Mount, Plug, 12Gb/s.
线束工程师服务平台
可以搜到:产品、技术、资料、新闻、检测、企业、视频

| TE | 10132583-001LF |
| 分类 | 连接器 |
| 类型 | amphenol-icc |
| 品牌 | 安费诺(Amphenol-ICC) |
| 描述 | SAS/PCIe 3.0 (U.2) Connectors, Storage and Server Connector, 68 Position Right Angle,Straddle Mount, Plug, 12Gb/s. |
| Gender | Header |
| 孔位数 | 68 |
| Number of Contacts | 68 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Termination Style | Straddle Mount |
| Pitch | 1.27mm (0.050in) & 0.80mm (0.031in) |
| 颜色 | Black |
| Housing Height | 5.80mm (0.228in) |
| Current Rating | 1.5A at 30°C |
| Voltage Rating | 500V AC |
| Durability (Mating cycles) | 500 Mating Cycles |
| Material Contact | Copper Alloy |
| Flammability Rating | UL 94 V-0 |
| Tail Plating | Matt Tin |
| Plating Contact Area | 0.76μm (30μin) Gold |
| Material Housing | High Temperature Plastic, UL94V-1 |
| Operating Temperature Range | 0°C to +55°C |
| Retention Feature | Screw |
| Solder process | Compatible with Reflow Processes |
| Ul file number | E66906 |
| Packaging | Tube |
| Resistance (Contact) | 30mΩ max. (Initial) |
| Resistance (Insulation) | 1000MΩ min. |
| Plating Contact area | 30μin Gold |
