532617013
- 类 型:
- 连接器
- 品 牌:
- 莫仕(Molex)
- 颜 色:
- Natural
- 产品描述:
- 1.25mm Pitch, PicoBlade PCB Header, Single Row, Right-Angle, Surface Mount, Gold (Au) Plating, Friction Lock, 13 Circuits, Tape and Reel
线束工程师服务平台
可以搜到:产品、技术、资料、新闻、检测、企业、视频

| TE | 532617013 |
| 分类 | 连接器 |
| 类型 | PCB Headers |
| 品牌 | 莫仕(Molex) |
| Status | Active |
| 描述 | 1.25mm Pitch, PicoBlade PCB Header, Single Row, Right-Angle, Surface Mount, Gold (Au) Plating, Friction Lock, 13 Circuits, Tape and Reel |
| Series | 53261 |
| Application | Signal, Wire-to-Board |
| Overview | PicoBlade Connector System |
| UPC | 191128467711 |
| 孔位数 | 13.0 |
| 颜色 | Natural |
| Circuits (Loaded) | 13 |
| Lock to Mating Part | Yes |
| Material - Metal | Phosphor Bronze |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Matte Tin |
| Material - Resin | Polyamide |
| Net Weight | 338.845/mg |
| Number of Rows | 1 |
| Packaging Type | Embossed Tape on Reel |
| Pitch - Mating Interface | 1.25mm |
| Plating min - Mating | 0.380µm |
| Plating min - Termination | 1.000µm |
| Termination Interface: Style | Surface Mount |
