933344001
- 类 型:
- 连接器
- 品 牌:
- 莫仕(Molex)
- 颜 色:
- Natural
- 产品描述:
- 2.50mm Pitch Appli-Mate RAST 2.5 IDT Connector, Direct/Indirect, Female, 11 Circuits, with Bead-On Terminal, Fully Coded
线束工程师服务平台
可以搜到:产品、技术、资料、新闻、检测、企业、视频

| TE | 933344001 |
| 分类 | 连接器 |
| 类型 | IDT and Solder Connectors |
| 品牌 | 莫仕(Molex) |
| Status | Active |
| 描述 | 2.50mm Pitch Appli-Mate RAST 2.5 IDT Connector, Direct/Indirect, Female, 11 Circuits, with Bead-On Terminal, Fully Coded |
| Series | 93334 |
| Overview | RAST Connector System |
| UPC | 887191548449 |
| 孔位数 | 11.0 |
| 颜色 | Natural |
| Circuits (Loaded) | 11 |
| 连接器类型 | 母端 |
| Gender | Female |
| Lock to Mating Part | None |
| Material - Metal | Phosphor Bronze |
| Material - Plating Mating | Tin |
| Material - Plating Termination | Tin |
| Material - Resin | Polyamide |
| Net Weight | 2.438/g |
| Number of Rows | 1 |
| Packaging Type | Tray |
| Pitch - Mating Interface | 2.50mm |
| Plating min - Mating | 1.016µm |
| Plating min - Termination | 1.016µm |
| Termination Interface: Style | IDT or Pierce |
| Wire Size AWG | 22, 24 |
