| TE | 111-01169 |
| 分类 | 扎带 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals Application More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to MCT50L Competences Cable Ties and Fixings Cable clips for edges: fasten cables without drilling Accessories Similar products |
| 描述 | Total metal dispersion throughout the tie available in a wide range of sizes Usable as part of HACCP process Greatly reduces risk of contamination Magnetic and X-Ray detectable versions available |
| Application Tool | MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK9P, MK20, MK21, EVO7, EVO7SP, EVO9 |
| Colour | Green (GN) |
| Identification Plate Position | none |
| Pack Cont. | 100pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | MCT50L-PA66MP-GN |
| Product Family | MCT-Series, PA66MP |
| Product Group | Cable ties for food industry, detectable |
| Releasable Closure (Yes/No) | No |
| Short Description | Metal Content Tie 380x4.7 mm, green |
| 颜色 | Green (GN) |
| Tie Closure | plastic pawl |
| Variant | Inside Serrated |
| Bundle ∅ max. | 110.0mm |
| Bundle ∅ min. | 1.5mm |
| Length (L) | 380.0mm |
| Min.Tensile Strength | 225N |
| Width (W) | 4.7mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Halogenfree | Yes |
| Hazardous good | No |
| Material | Polyamide 6.6, with metal particles (PA66MP) |
| Operating Temperature - °C | -40 °C to +85 °C, (+105 °C, 500 h) |
| GTIN-13 / EAN | 5022660337161.0 |
| Packaging 1 - Height (m) | 0.04m |
| Packaging 1 - Length (m) | 0.424m |
| Packaging 1 - Qty | 100.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00231m³ |
| Packaging 1 - Weight (kg) | 0.282kg |
| Packaging 1 - Width (m) | 0.136m |
