| TE | 111-01017 |
| 分类 | 扎带 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals Application More products in this product group Base Data Product Dimensions Material and Specifications More Information Further information to T120R Competences Cable Ties and Fixings Cable clips for edges: fasten cables without drilling Accessories Similar products |
| 描述 | UV-resistant black cable tie available in a wide range of sizes Made from 100 % high quality plastic, allows for good recycling Inside serration for a strong hold onto bundles Easy application either manually or with a processing tool Simple to insert due to bent tail |
| Application Tool | EVOcut, MK9P, MK9P w/ Upper air, MK21, EVO7, EVO7SP, EVO9, EVO9HT |
| Colour | Green (GN) |
| Identification Plate Position | none |
| Pack Cont. | 100pcs. |
| PART DESCRIPTION | T120R-PA66W-GN |
| Product Family | T-Series in PA66W black |
| Product Group | Cable Ties for outdoor use (UV-resistant) |
| Releasable Closure (Yes/No) | No |
| 颜色 | Green (GN) |
| Tie Closure | plastic pawl |
| Variant | Inside Serrated |
| Bundle ∅ max. | 100mm |
| Bundle ∅ min. | 3.0mm |
| Length (L) | 388.0mm |
| Min.Tensile Strength | 535N |
| Width (W) | 7.6mm |
| Flammability | UL 94 V2 |
| Halogenfree | Yes |
| Material | Polyamide 6.6, UV-resistant (PA66W) |
| Operating Temperature - °C | -40 °C to +85 °C, (+105 °C, 500 h) |
